ASL INTERCOM iPAM400 User Manual

iPAM400 – Product Manual
U-0629-0171.doc – Issue: 04 complete, approved
Page 123 of 138
9.4 MX400
General
Output Power ....................................................................................................................................... 400 W @ 100 V RMS
1
Output Voltage and Input Sensitivity .................................................100 V RMS into 25 Ω load for 0 dBu 1 kHz input signal
Regulation.................................................................................................................no load to full load, better than 1.5 dB
Efficiency........................................................................................................................................................................ 80%
Quiescent Current (@ 24 V supply)
No signal ............................................................................................................................................................... 90 mA
With one or two AEL01/AEL02 units connected .................................................................................. 125 mA (nominal)
With continuous surveillance signal ................................................................................................... 150 mA (nominal)
Full Power Current (worst case 21 V battery supply) .................................................................................................... 25 A
Fusing .............................................................................................................................................................. 2 x F15A 1¼"
Frequency Response......................................................................................................................... 100 Hz – 18 kHz, ±3 dB
THD (@ 100 V RMS output, full load)............................................................................................................... <0.5% @ 1 kHz
Residual Noise ......................................................................................... better than 80 dB (A-weighted) below full output
Environmental
Refer to the iPAM400 specification.
Dimensions and Weight
Dimensions (H x W x D) ......................................................................... 79 mm x 316 mm x 273 mm (including connectors)
Weight..........................................................................................................................................................................5.4 kg
1
ASL amplifiers on 230 V mains power can produce full output, with normal programme material, into loads 25% greater than
those specified. In these conditions, a MX400 will deliver full output with 500 W of load connected.
