iPAM400 – Product Manual
U-0629-0171.doc – Issue: 04 complete, approved
Page 26 of 138
Mainframe Controls
Control Function
1
Earth Lift Switch
The Earth Lift switch is provided to allow removal of the mains earth from the signal circuits.
This may be required in order to eliminate ground loops between connected equipment.
Possible settings: DOWN (
, ON) or UP ( , OFF)
It is normally set to DOWN (
, ON) unless a +ve ground battery system is used, or it is
necessary to avoid a ground loop
problem; see Section “5.4 Avoiding Ground Loop Problems”
(page 58).
Switch
No.
Switch Name
Function when ON (down
position)
Function when OFF
(up position)
SW1 Debug
For ASL use only (for
software debug and
configuration purposes).
Always set this switch to OFF.
SW2
Mains Fault
Reporting Enable
AC mains input faults
ARE reported.
AC mains input faults ARE NOT
reported.
Use only when the mainframe is
being supplied from batteries
only.
SW3
Battery Fault
Reporting Enable
Battery supply input
faults ARE reported.
Battery supply input faults ARE
NOT reported.
Use only when the mainframe is
being supplied from AC mains
only (no batteries).
2
Mode DIP Switch
SW4
Aux Supply Fault
Reporting Enable
Aux supply output faults
ARE reported.
Aux supply output faults ARE
NOT reported.
Use only when the auxiliary DC
supply output is not being used
to power other equipment.
Rear Panel Indicators
Indicator Type Indication
RX Green LED RS485 receiving.
3
RS485 Port Status
TX Green LED RS485 transmitting.
activity Yellow LED Flashes when receiving Ethernet data packets.
4
Ethernet Port
Status
link Green LED
Illuminates when the Ethernet cables are connected and
terminated correctly.
