Chapter 4 INTERFACE SETTINGS
191
(3) Split mode
The left half of the video data is output from Port1, and the right half of the video data from Port2.
・・・・・・・
D0
[9..0]
D1
[9..0]
D2
[9..0]
D3
[9..0]
D638
[9..0]
D639
[9..0]
D640
[9..0]
D641
[9..0]
D642
[9..0]
D643
[9..0]
D1278
[9..0]
D1279
[9..0]
・・・・・・・
・・・・・・・
Clock
(54MHz)
Port1
Port2
(4) Split Mode（VM-1826） - Horizontally*
Port1 outputs upper half, and Port2 outputs bottom half.
Port 1
Port 2
Port1 Port2
