(5) Split Mode（VM-1826） - Vertically *
Port1 outputs left half. Ports 2 outputs right half.
Port 1 Port 2
* Note) Split mode (4Kx2K support) of VM-1826 is option.
c) Concerning the bit length setting
The valid bit length settings differ according to the video format as follows.
bit Width Video Format
6bit 8bit 10bit 12bit
RGB
( (
X
YCbCr4:2:2
( ( ( (
YCbCr4:4:4
( ( (
X
Caution: When the YCbCr4:2:2 format has been selected, up to 12 bits can be set as the bit length.
However, it is not possible to display the gray scale which is set in the “bit length (step)”. Use this
parameter to check the Main Stream Attribute parameters rather than using it to check the image
quality.
