ASTRO VG-873 - Page 86

68
 Vendor Specific InfoFrame
The vendor specific information is stored in Vendor Specific InfoFrame, and sent.
This setting determines whether Vendor Specific InfoFrame is to be sent.
0
OFF
The Vendor Specific InfoFrame is not sent.
(1)
OFF/ON
1
ON
The Vendor Specific InfoFrame is sent.
Listed below are the Vendor Specific InfoFrame settings.
* These settings are not related to the video and audio output settings.
This is the Vendor Specific InfoFrame type setting. (2)
Type
1 * “Type” is displayed only. It cannot be changed.
This is the Vendor Specific InfoFrame version setting. (3)
Version
1 * “Version” is displayed only. It cannot be changed.
This selects the format setting for the IEEE Registration ID and the items after
it.
0
Other
Any IEEE Registration ID can be selected.
The Payload is set after the IEEE Registration
ID.
(4)
IEEE RegID Sel
1
HDMI
The IEEE Registration ID is set to 000C03.
After the IEEE Registration ID, the setting is
established using the format that supports HDMI
1.4.
1. IEEE RegID Sel: Other
This is the IEEE Registration ID setting. 1-(1)
IEEE Regist. ID
000000 – FFFFFF
This is the Payload length setting. 1-(2)
Payload Length
0 – 24
This is the Payload data setting. 1-(3)
Payload 1-24
00 – FF
2. IEEE RegID Sel: HDMI
This indicates the IEEE Registration ID. (It cannot be changed.) 2-(1)
IEEE Regist. ID
000C03
This is the HDMI Video Format setting.
0
None
No additional HDMI video format is presented in
this packet.
1
Ext. Resolution
Extended resolution format present.
2-(2)
Video Format
2
3D
(Option)
3D format indication present.
* ‘3D’ is an option. The Vendor Specific
InfoFrame information is not sent unless the
license has been registered. For further
details, contact your dealer or an
ASTRODESIGN sales representative.
2-1. Video Format: Ext. Resolution
This is the HDMI VIC setting.
0
4K×2K 29.97/30 Hz
1
4K×2K 25 Hz
2
4K×2K 23.98/24 Hz
2-1-(1)
HDMI VIC
3
4K×2K 24 Hz (SMPTE)
