Chapter 4 INTERFACE SETTINGS
69
2-2. Video Format: 3D (Option)
this is the 3D Structure setting.
0
Frame Packing
1
Field Alternative *1
2
Line Alternative
3
Side-by-Side (Full)
4
L + depth
5
L + d + G + G-d (L + depth + graphics + graphics-depth)
6
Side-by-Side (Half)
2-2-(1)
3D Structure
7
Top & Bottom
this is the 3D Ext Data setting.
0
*2
Horizontal O/L,O/R
Horizontal sub-sampling
Odd/Left picture, Odd/Right picture
1
*2
Horizontal O/L,E/R
Horizontal sub-sampling
Odd/Left picture, Even/Right picture
2
*2
Horizontal E/L,O/R
Horizontal sub-sampling
Even/Left picture, Odd/Right picture
3
*2
Horizontal E/L,E/R
Horizontal sub-sampling
Even/Left picture, Even/Right picture
4
Quincunx O/L,O/R
Quincunx matrix
Odd/Left picture, Odd/Right picture
5
Quincunx O/L,E/R
Quincunx matrix
Odd/Left picture, Even/Right picture
6
Quincunx E/L,O/R
Quincunx matrix
Even/Left picture, Odd/Right picture
2-2-(2)
3D Ext Data
7
Quincunx E/L,E/R
Quincunx matrix
Even/Left picture, Even/Right picture
this is the 3D Meta present (whether the following 3D metadata is present or
not) setting.
0
0 (Not Present)
3D metadata not present
2-2-(3)
3DMeta Present
1
1
3D metadata present
this indicates the 3D Metadata type. (it cannot be changed.) 2-2-(4)
Metadata Type
0
this is the 3D Metadata Length setting. 2-2-(5)
Metadata Length
0 – 21 *3
this is the 3D Metadata data setting. 2-2-(6)
Metadata 1-21
*3
00 – FF
*1:
The output signals differ from the ones in the standards. The DE signal is
high for three Vblank periods of the current Field Alternative.
CAUTION
*2:
The 3D Ext Data values of 0 to 3 have all been made consistent with
“Horizontal sub-sampling” in HDMI Ver.1.4a standard.
With this generator, the old expressions are used to differentiate the drawing
method used with optional pattern 101 and to provide compatibility.
CAUTION
