If the setting value of 3D Structure is “Side-by-site (Half)”, the maximum data of 3D
Metadata is 20 bytes.
If you set “21” in Metadata Length, the last data (21st byte) is not sent.
Please refer to the below list.
Packet Byte# 7 6 5 4 3 2 1 0
PB 0 Checksum
PB 1
PB 2
PB 3
PB 4
PB 5
PB 6
PB 7
PB 8
PB 9
:
24bit IEEE Registration Identifier (000C03h)
( least significant byte first )
HDMI_Video_Format
(010b(3D))
Rsvd
(0)
Rsvd
(0)
Rsvd
(0)
Rsvd
(0)
Rsvd
(0)
3D_Structure
3D_Metadata_
Present
Rsvd
(0)
Rsvd
(0)
Rsvd
(0)
3D_Metadata_Type 3D_Metadata_Length
3D_Metadata_1
3D_Metadata_2
PB 27
3D_Metadata_3
:
3D_Metadata_20
3D_Metadata_21
PB 26
例1：3D_Structureの設定が『Side-by-Side(Half)』以外の場合のパケットデータマッピング
Example 1: Packet data mapping except Side-by-Side(Half).
Packet Byte# 7 6 5 4 3 2 1 0
PB 0
Checksum
PB 1
PB 2
PB 3
PB 4
PB 5
PB 6
PB 7
PB 8
PB 9
PB 10
：
24bit IEEE Registration Identifier (000C03h)
( least significant byte first )
HDMI_Video_Format
(010b(3D))
Rsvd
(0)
Rsvd
(0)
Rsvd
(0)
Rsvd
(0)
Rsvd
(0)
3D_Structure
(1000b(Side-by-Side(Half)))
3D_Metadata_
Present
Rsvd
(0)
Rsvd
(0)
Rsvd
(0)
3D_Ext_Data Reserved (0)
3D_Metadata_Type 3D_Metadata_Length
3D_Metadata_1
3D_Metadata_2
PB 26
PB 27
3D_Metadata_3
3D_Metadata_19
:
3D_Metadata_20
例2：3D_Structureの設定が『Side-by-Side(Half)』の場合のパケットデータマッピング
Cau
tion
Example 2: Packet data mapping of Side-by-Side(Half).
