72
This is the Picture Aspect Ratio (aspect ratio of the video parts including Bar
of letter box, etc.) setting.
0
No Data
No Data
1
4:3
4:3
(9)
Picture Aspect
2
16:9
16:9
This is the Non-Uniform Picture Scaling (direction in which transmitted
images have been scaled) setting.
0
No Known
No Known non-uniform Scaling
1
Horizontal
Picture has been scaled horizontally
2
Vertical
Picture has been scaled vertically
(10)
Scaling
3
Horiz. & Vert.
Picture has been scaled horizontally and
vertically
This is the Colorimetry (the standard whose coefficients were used for
conversion into color difference signals) setting.
0
No Data
No Data
1
SMPTE170M
ITU601
SMPTE170M/ITU601
2
ITU709
ITU709
(11)
Colorimetry
3
Extended Valid
Extended Colorimetry Information Valid
This is the Video Format Identification Code setting. (12)
Video Code
0 - 64
For further details on the timings indicated by Code, refer to
CEA-861-D.
(13)
Repetition 1 - 10
This is the Pixel Repetition Factor setting.
(14)
Top Bar 0 - 65535
This is the Line Number of End of Top Bar setting (letter box top
bar size setting).
(15)
Bottom Bar 0 - 65535
This is the Line Number of Start of Bottom Bar setting (letter box
bottom bar size setting).
(16)
Left Bar 0 - 65535
This is the Pixel Number of End of Left Bar setting (pillar box left
bar size setting).
(17)
Right Bar 0 - 65535
This is the Pixel Number of Start of Right Bar setting (pillar box
right bar size setting).
This is the RGB Quantization Range setting (quantization range when RGB
images apply for Colorimetry).
0
Default
1
Limited Range
(18)
RGB Quan.Range
2
Full Range
This is the YCC Quantization Range setting (quantization range when YCC
images apply for Colorimetry).
0
Limited Range
(19)
YCC Quan.Range
1
Full Range
This is the Extended Colorimetry setting.
(This is referenced when Extended Valid has been set as the Colorimetry
setting.)
0
XvYCC601
1
XvYCC709
2
sYCC601
3
AdobeYCC601
(20)
Extended Colo.
4
AdobeRGB
