Atlas Copco PowerMACS 4000 User Manual

Set Up and Maintenance
9836 3521 01 123
 Spindle and bolt setup‟s, one for each item specified.
 Specified programs.
 A mode table for each station specifying the programs you have selected.
 SPC configured for measuring the final torque and angle for each of the bolts.
 A reporter for the ToolsTalk PowerMACS screen and a printer connected to the CC.
 A PLC project containing one POU (Program Organization Unit) and one resource, with one task,
for each station defined in the system. All POU's are copies of a predefined POU template.
The setup is complete in the sense that it will be possible to execute. It will therefore be a good starting
point for your own application.
