Tightening
392 9836 3521 01
Yield point torque high during monitoring
Yield point torque low during monitoring
Yield point angle high during monitoring
Yield point angle low during monitoring
Double Torque transducer error
Double Angle encoder error
Monitoring: Overflow in recording buffer. See description of parameter "Allow
monitoring buffer overrun" in Program Settings.
A/D converter used for torque measurement saturated
This is bit is set if any error bit(s) in the range 64 . 95 are set and only the first 8
bytes are included. That is, Type in the reporter is set to "I8".
The automatic loosening, defined using the "Run reverse before retry" parameters
on the Step – Rejects tab, failed.
Torque rate too high from check
Torque rate too low from check
Deviation too high from check
Threshold torque not reached for angle monitoring (see also chapter: Monitoring
Check – Angle )
Remove fastener torque limit reached (see also chapter: Program )
Absolute Position check high limit
Absolute Position check low limit
Station stop (Disconnect, problem reported from station to all bolts, connected bolts
get Station stop)
Detach, TC detach detected and reported by station
Bolt is in operational mode Disconnected NOK
Transducer protection, none configurable restriction active during all steps in cycle
Final torque too high during monitoring on second buffer
