Atlas Copco PowerMACS 4000 User Manual

Peripheral Devices
426 9836 3521 01
Station variables:
Variable
Order
Width
Dec
Type
Text
Lines
Data No
1
I2
Station No
2
I2
Time
3
I4
Mode No
4
I2
Bolt variables:
Variable
Order
Width
Dec
Type
Text
Lines
Bolt No
1
I2
Bolt T
2
F
Bolt A
3
F
Status
4
I2
You must also enable and configure the drivers used for accessing the PLC data. This is done using the
IO_Configuration worksheet for station in question.
The above setup (for a station containing one bolt) corresponds to the declaration of the following PLC
variables in the CycleData_Var section of the Global_Variables worksheet for the station in question:
