Atlas Copco PowerMACS 4000 User Manual

Peripheral Devices
9836 3521 01 507
blocks, the first six contains 64 * 6 = 384 bytes and the seventh 16 bytes.
Inputs to PowerMACS (that is, the AnyBus OUT area) are mapped as follows:
Class Id
Acyclic block No (bytes)
Instance Id
Attribute Id
0xA2 - Acyclic Data Input
1 (0 .. 63)
0x05
0x05
2 (64 .. 127)
0x06
0x05
3 (128 .. 191)
0x07
0x05
:
:
:
:
118 (7488 .. 7551)
0x7B
0x05
119 (7552 .. 7615)
0x7C
0x05
120 (7616 .. 7679)
0x7D
0x05
Outputs from PowerMACS (that is, the AnyBus IN area) is mapped as follows:
Class Id
Acyclic block No (bytes)
Instance Id
Attribute Id
0xA2 - Acyclic Data Output
1 (0 .. 63)
0x81
0x05
2 (64 .. 127)
0x82
0x05
3 (128 .. 191)
0x83
0x05
:
:
:
:
118 (7488 .. 7551)
0xF7
0x05
119 (7552 .. 7615)
0xF8
0x05
120 (7616 .. 7679)
0xF9
0x05
