Basic Functions
9836 3521 01 59
result information and background color remains. When the cycle is finished, the background color and
result information is updated.
In the case that the cycle is ended without any cycle data being produced (for example a sub cycle is
ended in a stitching cycle using PLC station output variable DATAHOLD); the bolt boxes background
color is updated to show the status of the finished cycle.
Note! The station box is still yellow to indicate that the complete tightening cycle is not yet finished and
that there is no result information in the bolt boxes. The reason for this is that the cycle data is not yet
produced by the system and therefore it is not possible to show any result information either. When the
complete cycle is finished and the cycle data is received, the station and bolt boxes are updated with
status and result information.
