Atlas Copco PowerMACS 4000 User Manual

Basic Functions
9836 3521 01 83
For each event the following information can be displayed (from left to right):
 If the event is observed or not (a check mark if observed)
 The severity of the event
 The date and time when the event occurred
 Number of the TC that generated the event (Optional)
 The number of the station to which the event belongs (zero (0) if not connected to a particular
station) (Optional)
 The number of the bolt (the user specified bolt number) to which the event belongs zero (0) if not
connected to a particular bolt) (Optional)
 The Angle Channel if relevant (for restriction, check and monitoring events). Possible values are:
 M Monitoring
 C Control
 1,2 Channel number
(Optional)
 The Torque Channel if relevant (for restrictions, check and monitoring events). Possible values are:
 M Monitoring
 C Control
 1,2,3 Channel Number (1-2 is torque transducers, 3 is Current As Torque)
(Optional)
 The name of the program to which the event belongs (blank if not connected to a particular
program)
 The type of the event
 The event code of the event (Optional)
 A textual description of the event
By default the Event Log window is docked on the bottom right half of the ToolsTalk PowerMACS main
window but can be placed freely.
