Version 7.0 1069 Mediant 3000
User's Manual 60. Technical Specifications
Function Specification
Hardware Specifications
Dimensions
(HxWxD) 88mm x 482.6mm x 296.8mm, 4-slot, 2U cPCI chassis
Weight
Approx. 35.27 lb (16 kg), fully loaded
Power
48 V DC Dual Feed, with up to 2 DC Power modules or 100–240 V AC
redundant Dual Feed
Regulatory Compliance
Telecommunication
Standards
FCC part 68, TBR4 and TBR13
Safety and EMC
Standards
 UL 60950-1
 FCC part 15 Class A
 CE mark (EN 55022 Class A, EN 60950, EN 55024, EN 300 386)
Environmental
NEBS Level 3, GR-63-Core, GR-1089-Core, Type 1 & 3, ETS 300 019
