User's Manual 53. Syslog and Debug Recording
53.3 Configuring Debug Recording
This section describes how to configure and activate debug recording, and how to collect
debug recording packets. For filtering debug recording packets for specific calls, see
''Configuring Log Filter Rules'' on page 789.
Notes:
• Debug recording is collected only on the device's OAMP interface.
• For a detailed description of the debug recording parameters, see ''Syslog, CDR
and Debug Parameters'' on page 858.
53.3.1 Configuring Address of Debug Recording Server
The procedure below describes how to configure the address of the debug recording
(capturing) server to where the device sends the captured traffic. Once you configure an
address, the device generates DR packets for all calls. However, you can configure the
device to generate DR packets for specific calls, using Logging Filter rules in the Logging
Filters table (see ''Configuring Log Filter Rules'' on page 789).
 To configure the debug recording server's address:
1. Open the Logging Settings page (Configuration tab > System menu > Logging >
Logging Settings).
Figure 53-8: Logging Settings Page
2. In the 'Debug Recording Destination IP' field, configure the IP address of the debug
capturing server.
3. In the 'Debug Recording Destination Port' field, configure the port of the debug
capturing server.
4. Click Submit.
53.3.2 Collecting Debug Recording Messages
To collect debug recording packets, use the open source packet capturing program,
Wireshark. AudioCodes proprietary plug-in files for Wireshark are required.
Notes:
• The default debug recording port is 925. You can change the port in Wireshark
(Edit menu > Preferences > Protocols > AC DR).
• The plug-in files are per major software release of Wireshark. For more
information, contact your AudioCodes sales representative.
• The plug-in files are applicable only to Wireshark 32-bit for Windows.
