AudioCodes Mediant 3000 User Manual

Version 7.0 203 Mediant 3000
User's Manual 15. Media
3. Set the ini file parameter, BellModemTransportType to 2 (Bypass).
4. Set the ini file parameter, NSEMode parameter to 1 (enables NSE).
5. Set the ini file parameter, NSEPayloadType parameter to 100.
15.2.2.6 Fax / Modem Transparent with Events Mode
In this mode, fax and modem signals are transferred using the current voice coder with the
following automatic adaptations:

Echo Canceller = on (or off for modems)

Echo Canceller Non-Linear Processor Mode = off

Jitter buffering optimizations
 To configure fax / modem transparent with events mode:
1. In the SIP General Parameters page (Configuration tab > VoIP menu > SIP
Definitions > General Parameters), set the 'Fax Signaling Method' parameter to No
Fax (IsFaxUsed = 0).
2. In the Fax/Modem/CID Settings page, do the following:
a. Set the 'Fax Transport Mode' parameter to Events Only (FaxTransportMode =
3).
b. Set the 'V.21 Modem Transport Type' parameter to Events Only
(V21ModemTransportType = 3).
c. Set the 'V.22 Modem Transport Type' parameter to Events Only
(V22ModemTransportType = 3).
d. Set the 'V.23 Modem Transport Type' parameter to Events Only
(V23ModemTransportType = 3).
e. Set the 'V.32 Modem Transport Type' parameter to Events Only
(V32ModemTransportType = 3).
f. Set the 'V.34 Modem Transport Type' parameter to Events Only
(V34ModemTransportType = 3).
3. Set the ini file parameter, BellModemTransportType to 3 (transparent with events).
15.2.2.7 Fax / Modem Transparent Mode
In this mode, fax and modem signals are transferred using the current voice coder without
notifications to the user and without automatic adaptations. It's possible to use Profiles (see
''Coders and Profiles'' on page 381) to apply certain adaptations to the channel used for fax
/ modem. For example, to use the coder G.711, to set the jitter buffer optimization factor to
13, and to enable echo cancellation for fax and disable it for modem.
 To configure fax / modem transparent mode:
1. In the SIP General Parameters page (Configuration tab > VoIP menu > SIP
Definitions > General Parameters), set the 'Fax Signaling Method' parameter to No
Fax (IsFaxUsed = 0).
2. In the Fax/Modem/CID Settings page, do the following:
a. Set the 'Fax Transport Mode' parameter to Disable (FaxTransportMode = 0).
b. Set the 'V.21 Modem Transport Type' parameter to Disable
(V21ModemTransportType = 0).
c. Set the 'V.22 Modem Transport Type' parameter to Disable
(V22ModemTransportType = 0).
