User's Manual 818 Document #: LTRT-89730
Mediant 3000
♦ Number of currently active test calls.
♦ Number of successfully answered calls out of the total number of calls
attempted (Answer Seizure Ratio or ASR).
• "Receiving (<number of active calls>)": test call has been automatically activated
by calls received for this configured test call endpoint from the configured remote
endpoint. When all these calls terminate, the status returns to "Idle".
• "Terminating (<number of active calls>)": the Drop Call command has been
clicked to stop the test call and the test call is in the process of terminating the
currently active test calls.
• "Done - Established Calls: <number of established calls>, ASR: <%>": test call
has been successfully completed (or was prematurely stopped by clicking the
Drop Call command) and shows the following:
♦ Total number of test calls that were established.
♦ Number of successfully answered calls out of the total number of calls
attempted (ASR).

MOS Status: MOS count and color threshold status of local and remote sides
according to the assigned QoE Profile.

Delay Status: Packet delay count and color-threshold status of local and remote sides
according to the assigned QoE Profile.

Jitter Status: Jitter count and color-threshold status of local and remote sides
according to the assigned QoE Profile.

Packet Loss Status: Packet loss count and color-threshold status of local and remote
sides according to the assigned QoE Profile.

Bandwidth Status: Tx/Rx bandwidth and color-threshold status according to the
assigned Bandwidth Profile.
Note: On the receiving side, when the first call is accepted in "Idle" state, statistics
are reset.
56.4 Configuring DTMF Tones for Test Calls
By default, no DTMF signal is played to an answered test call (incoming or outgoing).
However, you can enable this per configured test call in the Test Call table (see
''Configuring Test Call Endpoints'' on page 811). If enabled, the default DTMF signal that is
played is "3212333". You can change this as described below.
Notes:
• The DTMF signaling type (e.g., out-of-band or in-band) can be configured using
the 'DTMF Transport Type' parameter. For more information, see ''Configuring
DTMF Transport Types'' on page 213.
• To generate DTMF tones, the device's DSP resources are required.
 To configure the played DTMF signal to answered test call:
1. Open the Test Call Settings page (Configuration tab > System menu > Test Call >
Test Call Settings).
Figure 56-3: DTMF in Test Call Settings Page
