Version 7.0 945 Mediant 3000
User's Manual 58. Configuration Parameters Reference
Parameter Description
[ISDNKeypadMode]
Enables the device to send DTMF digits received in the called party
number from the IP side, as Keypad facility IE in ISDN INFORMATION
messages to PSTN.
 [0] Don’t send = (Default) All digits are sent as DTMF to PSTN (i.e.,
not sent as Keypad).
 [1] During Call Establishment = DTMF digits after * or # (inclusive)
are sent as Keypad only during call establishment and call
disconnect. During an established call, all digits are sent as DTMF.
 [2] Always = DTMF digits after * or # (inclusive) are always sent as
Keypad (call establishment, connect, and disconnect).
For more information, see Interworking Keypad DTMFs for SIP-to-ISDN
Calls on page 526.
Note: This feature is not applicable to re-INVITE messages.
58.10.3 Digit Collection and Dial Plan Parameters
The digit collection and dial plan parameters are described in the table below.
Table 58-43: Digit Collection and Dial Plan Parameters
Parameter Description
Dial Plan Index
[DialPlanIndex]
Defines the Dial Plan index to use in the external Dial Plan file. The
Dial Plan file is loaded to the device as a .dat file (converted using
the DConvert utility). The Dial Plan index can be defined globally or
per Tel Profile.
The valid value range is 0 to 7, where 0 denotes PLAN1, 1 denotes
PLAN2, and so on. The default is -1, indicating that no Dial Plan file
is used.
Notes:
 If the parameter is configured to select a Dial Plan index, the
settings of the parameter DigitMapping are ignored.
 If the parameter is configured to select a Dial Plan index from an
external Dial Plan file, the device first attempts to locate a
matching digit pattern in the Dial Plan file, and if not found, then
attempts to locate a matching digit pattern in the Digit Map rules
configured by the DigitMapping parameter.
 The parameter is applicable also to ISDN with overlap dialing.
 For E1 CAS MFC-R2 variants (which don't support terminating
digit for the called party number, usually I-15), the parameter
and the DigitMapping parameter are ignored. Instead, you can
define a Dial Plan template per trunk using the parameter
CasTrunkDialPlanName_x (or in the Trunk Settings page).
 The parameter can also be configured in a Tel Profile.
 For more information on the Dial Plan file, see ''Dialing Plans for
Digit Collection'' on page 684.
[Tel2IPSourceNumberMapping
DialPlanIndex]
Defines the Dial Plan index in the external Dial Plan file for the Tel-
to-IP Source Number Mapping feature.
The valid value range is 0 to 7, defining the Dial Plan index [Plan x]
in the Dial Plan file. The default is -1 (disabled).
