AudioCodes Mediant 3000 User Manual

Version 7.0 741 Mediant 3000
User's Manual 50. Performance Monitoring
Table 50-1: Additional Graph Functionality for Trunk Utilization
Button Description
Add button
Displays additional trunks in the graph. Up to five trunks can be
displayed simultaneously in the graph. To view another trunk, click this
button and then from the new 'Trunk' drop-down list, select the required
trunk.
Each trunk is displayed in a different color, according to the legend
shown in the top-left corner of the graph.
Remove button
Removes the selected trunk display from the graph.
Disable check box
Hides or shows an already selected trunk. Select this check box to
temporarily hide the trunk display; clear this check box to show the trunk.
This is useful if you do not want to remove the trunk entirely (using the
Remove button).
Get Most Active button
Displays only the trunk with the most active channels (i.e., trunk with the
most calls).
Pause button
Pauses the display in the graph.
Play button
Resumes the display in the graph.
Zoom slide ruler and
buttons
Increases or reduces the trunk utilization display resolution concerning
time. The Zoom In button increases the time resolution; the
Zoom Out button decreases it. Instead of using the buttons, you
can use the slide ruler. As you increase the resolution, more data is
displayed on the graph. The minimum resolution is about 30 seconds;
the maximum resolution is about an hour.
50.3 Viewing Quality of Experience
The Quality Of Experience page provides statistical information on calls per SRD or IP
Group. The statistics can be further filtered to display incoming and/or outgoing call
direction, and type of SIP dialog (INVITE, SUBSCRIBE, or all).
Note: The Quality Of Experience page is applicable only to SBC calls.
This page provides three pie charts:

Dialog Success Ratio: displays the SIP call and subscribe (SUBSCRIBE) dialog
success-failed ratio.

Dialog Failed Attempts: displays the failed call attempts. This includes the number of
calls and subscribes which were successfully and abnormally terminated.

Dialog Termination Ratio: displays call termination by reason (e.g., due to no answer).
