User's Manual 982 Document #: LTRT-89730
Mediant 3000
Parameter Description
DS3CONFIG 0 = 0, 1, 2, , 1, 1, 0, 1;
Note: For a description of the parameters included in this table,
refer to their individual parameter descriptions below.
Framing Method
[DS3Config_FramingMethod]
Determines the physical DS3 framing method for the interface.
ï‚§ [0] M23 = (Default) M23 framing.
ï‚§ [1] C Bit Parity = C Bit Parity.
Clock Source
[DS3Config_ClockSource]
Determines the DS3 clock mode for the interface.
ï‚§ [0] External = DS3 clock is recovered from the line.
ï‚§ [1] Local Board = (Default) DS3 trunk clock source is provided
by the device's internal clock.
Line Build Out
[DS3Config_LineBuildOut]
Determines the DS3 line build out (i.e., the level of signal transmit).
This level influences the cable length that can be used with the
device.
ï‚§ [2] = level 1
ï‚§ [3] = Level 2
ï‚§ [4] = Level 3
ï‚§ [5] = Level 4 (default)
ï‚§ [6] = Level 5
ï‚§
[7]
= Level 6
[DS3Config_CircuitIdentifier] Defines the interface SNMP name, which is represented by a string
of up to 15 characters. By default, no value is defined.
[DS3Config_TrapEnable] Enables SNMP traps for DS3.
ï‚§ [0] = Disable
ï‚§
[1]
= Enable (default)
[DS3Config_PmOnOff] Enables performance monitoring for the DS3 interface.
ï‚§ [0] = Disables performance monitoring for the specific DS3
interface.
ï‚§
[1]
= (Default) Enable.
[DS3Config_TappingEnable] Enables special DS3 Tapping mode. In this mode, the interface is
capable of receiving a signal with additional 14-dB attenuation to
the standard maximum length.
ï‚§ [0] = Disable (default)
ï‚§
[1]
= Enable
Administrative State
[DS3Config_AdminState]
Determines the DS3 interface Administrative status. When the
interface Administrative status is set to Down, all 28 underlying
DS1 interfaces are unavailable.
ï‚§ [1] Up = (Default) Administrative status Up.
ï‚§ [2] Down = Administrative status Down (currently, not
supported).
58.10.6.6 SDH/SONET Parameters
The SDH/SONET parameters are described in the table below.
Note: SDH/SONET interface is applicable only to Mediant 3000 with TP-6310.
