Version 7.0 765 Mediant 3000
User's Manual 52. Reporting Information to External Party
[S=40] |SBCReportType |EPTyp |SIPCallId |SessionId |Orig |SourceIp
|SourcePort |DestIp |DestPort |TransportType |SrcURI
|SrcURIBeforeMap |DstURI |DstURIBeforeMap |Durat |TrmSd |TrmReason
|TrmReasonCategory |SetupTime |ConnectTime |ReleaseTime
|RedirectReason |RedirectURINum |RedirectURINumBeforeMap
|TxSigIPDiffServ|IPGroup (description) |SrdId (name)
|SIPInterfaceId |ProxySetId |IpProfileId (name) |MediaRealmId
(name) |DirectMedia |SIPTrmReason |SIPTermDesc |Caller |Callee
[S=41] |CALL_END |SBC |20767593291410201017029@10.33.45.80
|1871197419|LCL |10.33.45.80 |5060 |10.33.45.72 |5060 |UDP
|9001@10.8.8.10 |9001@10.8.8.10 |6001@10.33.45.80
|6001@10.33.45.80 |15 |LCL |GWAPP_NORMAL_CALL_CLEAR
|NORMAL_CALL_CLEAR |17:00:29.954 UTC Thu Oct 14 2014
|17:00:49.052 UTC Thu Oct 14 2014 |17:01:04.953 UTC Thu Oct 14
2014 |-1 | | |40 |1 |0 (SRD_GW) |1 |1 |1 () |0 (MR_1) |no |BYE
|Q.850 ;cause=16 ;text="loc |user 9928019 |
52.2.1.2 CDR Fields for SBC Media
The default CDR fields for SBC media are listed in the table below. The media CDRs are
published for each active media stream, thereby allowing multiple media CDRs, where
each media CDR has a unique call ID corresponding to the signaling CDR.
Table 52-3: Default CDR Fields for SBC Media
CDR Field Name Description
MediaReportType
Report type (media start, update, or end)
SIPCallId
Unique call ID
Cid
Channel CID
MediaType
Media type (audio, video, or text)
Coder
Coder name
PacketInterval
Coder packet interval
LocalRtpIp
Local RTP IP address
LocalRtpPort
Local RTP port
RemoteRtpIp
Remote RTP IP address
RemoteRtpPort
Remote RTP port
InPackets
Number of received packets
OutPackets
Number of sent packets
LocalPackLoss
Local packet loss
RemotePackLoss
Remote packet loss
RTPdelay
RTP delay
RTPjitter
RTP jitter
TxRTPssrc
Tx RTP SSRC
RxRTPssrc
Local RTP SSRC
