Version 7.0 669 Mediant 3000
User's Manual 41. Basic Maintenance
41 Basic Maintenance
The Maintenance Actions page allows you to perform the following:
Reset the device - see ''Resetting the Device'' on page 669
Lock and unlock the device - see ''Locking and Unlocking the Device'' on page 671
Save configuration to the device's flash memory - see ''Saving Configuration'' on page
672
To access the Maintenance Actions page, do one of the following:
On the toolbar, click the Device Actions button, and then from the drop-down menu,
choose Reset.
On the Navigation bar, click the Maintenance tab, and then in the Navigation tree,
select the Maintenance menu and choose Maintenance Actions.
Figure 41-1: Maintenance Actions Page
41.1 Resetting the Device
The Maintenance Actions page allows you to remotely reset the device. Before resetting
the device, you can also choose the following options:
"Burn" (save) the device's current configuration to the device's flash memory (non-
volatile).
Graceful Shutdown, whereby the device resets only after a user-defined time (i.e.,
timeout) or after there is no traffic currently processed by the device (the earliest
thereof).
Notes:
• Throughout the Web interface, parameters displayed with a lightning symbol
are not applied on-the-fly and require that you reset the device for them to take
effect.
• When you modify parameters that require a device reset, once you click the
Submit button in the relevant page, the toolbar displays "Reset" (see ''Toolbar
Description'' on page 64) to indicate that a device reset is required.
• After you reset the device, the Web GUI is displayed in Basic view (see
''Displaying Navigation Tree in Basic and Full View'' on page 65).
