User's Manual 670 Document #: LTRT-89730
Mediant 3000
 To reset the device:
1. Open the Maintenance Actions page (see ''Basic Maintenance'' on page 669).
2. Under the 'Reset Configuration' group, from the 'Burn To FLASH' drop-down list,
select one of the following options:
• Yes: The device's current configuration is saved (burned) to the flash memory
prior to reset (default).
• No: Resets the device without saving the current configuration to flash (discards
all unsaved modifications).
3. Under the 'Reset Configuration' group, from the 'Graceful Option' drop-down list,
select one of the following options:
• Yes: Reset starts only after the user-defined time in the 'Shutdown Timeout' field
(see Step 4) expires or after no more active traffic exists (the earliest thereof). In
addition, no new traffic is accepted.
• No: Reset starts regardless of traffic, and any existing traffic is terminated at
once.
4. Under the 'Reset Configuration' group, in the 'Shutdown Timeout' field (relevant only if
the 'Graceful Option' in the previous step is set to Yes), enter the time after which the
device resets. Note that if no traffic exists and the time has not yet expired, the device
resets.
5. Click the Reset button; a confirmation message box appears, requesting you to
confirm.
Figure 41-2: Reset Confirmation Message Box
6. Click OK to confirm device reset; if the parameter 'Graceful Option' is set to Yes (in
Step 3), the reset is delayed and a screen displaying the number of remaining calls
and time is displayed. When the device begins to reset, a message appears notifying
you of this.
