Version 7.0 161 Mediant 3000
User's Manual 13. Network
Table 13-12: Internal DNS Table Parameter Description
Parameter Description
Domain Name
[Dns2Ip_DomainName]
Defines the host name to be translated.
The valid value is a string of up to 31 characters.
First IP Address
[Dns2Ip_FirstIpAddress]
Defines the first IP address (in dotted-decimal format notation) to
which the host name is translated. The IP address can be
configured as an IPv4 and/or IPv6 address.
Second IP Address
[Dns2Ip_SecondIpAddress]
Defines the second IP address (in dotted-decimal format notation)
to which the host name is translated.
Third IP Address
[Dns2Ip_ThirdIpAddress]
Defines the third IP address (in dotted-decimal format notation) to
which the host name is translated.
Fourth IP Address
[Dns2Ip_FourthIpAddress]
Defines the fourth IP address (in dotted-decimal format notation) to
which the host name is translated.
Note: Currently, this parameter is not supported.
13.7.2 Configuring the Internal SRV Table
The Internal SRV table resolves host names to DNS A-Records. Three different A-Records
can be assigned to each host name, where each A-Record contains the host name,
priority, weight, and port.
Note: If you configure the Internal SRV table, the device initially attempts to resolve a
domain name using this table. If the domain is not configured in the table, the device
performs a Service Record (SRV) resolution using an external DNS server,
configured in the Interface table (see ''Configuring IP Network Interfaces'' on page
145).
The following procedure describes how to configure the Internal SRV table through the
Web interface. You can also configure it through ini file (SRV2IP).
 To configure an SRV rule:
1. Open the Internal SRV table (Configuration tab > VoIP menu > Network > DNS >
Internal SRV Table).
