User's Manual 162 Document #: LTRT-89730
Mediant 3000
2. Click Add; the following dialog box appears:
Figure 13-6: Internal SRV Table - Add Row Dialog Box
3. Configure an SRV rule according to the parameters described in the table below.
4. Click Add, and then save ("burn") your settings to flash memory.
Table 13-13: Internal SRV Table Parameter Descriptions
Parameter Description
Domain Name
[Srv2Ip_InternalDomain]
Defines the host name to be translated.
The valid value is a string of up to 31 characters. By default, no
value is defined.
Transport Type
[Srv2Ip_TransportType]
Defines the transport type.
 [0] UDP (default)
 [1] TCP
 [2] TLS
DNS Name (1-3)
[Srv2Ip_Dns1/2/3]
Defines the first, second or third DNS A-Record to which the host
name is translated.
By default, no value is defined.
Priority (1-3)
[Srv2Ip_Priority1/2/3]
Defines the priority of the target host. A lower value means that it is
more preferred.
By default, no value is defined.
Weight (1-3)
[Srv2Ip_Weight1/2/3]
Defines a relative weight for records with the same priority.
By default, no value is defined.
