User's Manual 174 Document #: LTRT-89730
Mediant 3000
Firewall Settings).
2. Click Add; the following dialog box appears:
Figure 14-1: Firewall Settings Table - Add Row Dialog Box
3. Configure a Firewall rule according to the parameters described in the table below.
4. Click Add, and then reset the device with a burn-to-flash for your settings to take
effect.
Table 14-1: Firewall Settings Table Parameter Descriptions
Parameter Description
Index Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Source IP
[AccessList_Source_IP]
Defines the IP address (or DNS name) or a specific host name of the
source network (i.e., from where the incoming packet is received).
The default is 0.0.0.0.
Source Port
[AccessList_Source_Port]
Defines the source UDP/TCP ports (of the remote host) from where
packets are sent to the device.
The valid range is 0 to 65535. The default is 0.
Note:
When set to 0, this field is ignored and any source port matches
the rule.
