User's Manual 180 Document #: LTRT-89730
Mediant 3000
2. Click Add; the following dialog box appears:
Figure 14-4: IDS Policy Table - Add Row Dialog Box
3. Configure an IDS Policy name according to the parameters described in the table
below.
4. Click Add.
Table 14-3: IDS Policy Table Parameter Descriptions
Parameter Description
Index
[IDSPolicy_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
[IDSPolicy_Name]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 40 characters.
Description
[IDSPolicy_Description]
Defines a brief description for the IDS Policy.
The valid value is a string of up to 100 characters.
5. In the IDS Policy table, select the required IDS Policy row, and then click the IDS Rule
Table link located below the table; the IDS Rule table opens:
Figure 14-5: IDS Rule Table of Selected IDS Policy
