User's Manual 198 Document #: LTRT-89730
Mediant 3000
rate. You can also enable or disable Error Correction Mode (ECM) fax mode using the 'Fax
Relay ECM Enable' parameter (FaxRelayECMEnable).
When using T.38 mode, you can define a redundancy feature to improve fax transmission
over congested IP networks. This feature is activated using the 'Fax Relay Redundancy
Depth' parameter (FaxRelayRedundancyDepth) and the 'Fax Relay Enhanced
Redundancy Depth' parameter (FaxRelayEnhancedRedundancyDepth). Although this is a
proprietary redundancy scheme, it should not create problems when working with other
T.38 decoders.
15.2.2.1.1 Switching to T.38 Mode using SIP Re-INVITE
In the Switching to T.38 Mode using SIP Re-INVITE mode, upon detection of a fax signal
the terminating device negotiates T.38 capabilities using a Re-INVITE message. If the far-
end device doesn't support T.38, the fax fails. In this mode, the 'Fax Transport Mode'
parameter (FaxTransportMode) is ignored.
 To configure T.38 mode using SIP Re-INVITE messages:
1. In the SIP General Parameters page (Configuration tab > VoIP menu > SIP
Definitions > General Parameters), set the 'Fax Signaling Method' parameter to T.38
Relay (IsFaxUsed = 1).
2. In the Fax/Modem/CID Settings page, configure the following optional parameters:
• 'Fax Relay Redundancy Depth' (FaxRelayRedundancyDepth)
• 'Fax Relay Enhanced Redundancy Depth'
(FaxRelayEnhancedRedundancyDepth)
• 'Fax Relay ECM Enable' (FaxRelayECMEnable)
• 'Fax Relay Max Rate' (FaxRelayMaxRate)
Note: The ter
minating gateway sends T.38 packets immediately after the T.38
capabilities are negotiated in SIP. The originating device sends no-op T.38 packets
after the T.38 capabilities are negotiated in SIP. For this feature to function, no-op
packets must be enabled (NoOpEnable = 1).
15.2.2.1.2 Automatically Switching to T.38 Mode without SIP Re-INVITE
In the Automatically Switching to T.38 Mode without SIP Re-INVITE mode, when a fax
signal is detected, the channel automatically switches from the current voice coder to
answer tone mode and then to T.38-compliant fax relay mode.
 To configure automatic T.38 mode:
1. In the SIP General Parameters page (Configuration tab > VoIP menu > SIP
Definitions > General Parameters), set the 'Fax Signaling Method' parameter to No
Fax (IsFaxUsed = 0).
2. In the Fax/Modem/CID Settings page, set the 'Fax Transport Mode' parameter to T.38
Relay (FaxTransportMode = 1).
3. Configure the following optional parameters:
• 'Fax Relay Redundancy Depth' (FaxRelayRedundancyDepth)
• 'Fax Relay Enhanced Redundancy Depth'
(FaxRelayEnhancedRedundancyDepth)
• 'Fax Relay ECM Enable' (FaxRelayECMEnable)
• 'Fax Relay Max Rate' (FaxRelayMaxRate)
