Version 7.0 235 Mediant 3000
User's Manual 16. Services
 To configure a SIP Recording Routing rule:
1. Open the SIP Recording page (Configuration tab > VoIP menu > Services > SIP
Recording).
2. Click Add; the following dialog box appears:
The figure above shows a configuration example where the device records calls made
by IP Group "ITSP" to IP Group "IP PBX" that have the destination number prefix,
"1800". The device records the calls from the leg interfacing with IP Group "IP PBX",
sending the recorded media to IP Group "SRS".
3. Configure a SIP recording route according to the parameters described in the table
below.
4. Click Add, and then save ("burn") your settings to flash memory.
Table 16-1: SIP Recording Table Parameter Descriptions
Parameter Description
Index
[SIPRecRouting_Index]
Defines an index number for the new table record.
Recorded IP Group
[SIPRecRouting_RecordedI
PGroupName]
Defines the IP Group participating in the call and the recording is done
on the leg interfacing with this IP Group. For configuring IP Groups, see
''Configuring IP Groups'' on page 343.
By default, all IP Groups are defined (Any).
Note: For an SBC RTP-SRTP session, the recorded IP Group must be
set to the RTP leg if recording is required to be RTP, or set to the SRTP
leg if recording is required to be SRTP.
Recorded Source Prefix
[SIPRecRouting_Recorded
SourcePrefix]
Defines calls to record based on source number or URI.
By default, all source numbers or URIs are defined (*).
Recorded Destination
Prefix
[SIPRecRouting_Recorded
DestinationPrefix]
Defines calls to record based on destination number or URI.
By default, all destination numbers or URIs are defined (*).
