AudioCodes Mediant 3000 User Manual

User's Manual 240 Document #: LTRT-89730
Mediant 3000
2. Click Add; the following dialog box appears:
Figure 16-2: RADIUS Servers Table - Add Row Dialog Box
3. Configure a RADIUS server according to the parameters described in the table below.
4. Click Add.
Table 16-2: RADIUS Servers Table Parameter Descriptions
Parameter Description
Index
[RadiusServers_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
IP Address
[RadiusServers_IPAddre
ss]
Defines the IP address of the RADIUS server (in dotted-decimal notation).
Authentication Port
[RadiusServers_Authenti
cationPort]
Defines the port of the RADIUS Authentication server for authenticating
the device with the RADIUS server. When set to any value other than 0,
the RADIUS server is used by the device for RADIUS-based
management-user login authentication. When set to 0, RADIUS-based
login authentication is not implemented.
The valid value is 0 to any integer. The default is 1645.
Accounting Port
[RadiusServers_Accounti
ngPort]
Defines the port of the RADIUS Accounting server to where the device
sends accounting data of SIP calls as call detail records (CDR). When set
to any value other than 0, the RADIUS server is used by the device for
RADIUS-based accounting (CDR). When set to 0, RADIUS-based
accounting is not implemented.
The valid value is 0 to any integer. The default is 1646.
Shared Secret
[RadiusServers_SharedS
ecret]
Defines the shared secret (password) for authenticating the device with
the RADIUS server. This should be a cryptically strong password. The
shared secret is also used by the RADIUS server to verify the
authentication of the RADIUS messages sent by the device (i.e., message
integrity).
The valid value is up to 48 characters. By default, no value is defined.
