Version 7.0 277 Mediant 3000
User's Manual 16. Services
The following procedure describes how to configure Time Bands per Cost Group through
the Web interface. You can also configure it through ini file (CostGroupTimebands).
 To configure a Time Band per Cost Group:
1. Open the Cost Group table (Configuration tab > VoIP menu > Services > Least
Cost Routing > Cost Group Table).
2. Select a Cost Group for which you want to assign Time Bands, and then click the
Time Band link located below the table; the Time Band table for the selected Cost
Group appears.
3. Click Add; the following dialog box appears:
4. Configure a Time Band according to the parameters described in the table below.
5. Click Add, and then save ("burn") your settings to flash memory.
Table 16-12: Time Band Table Description
Parameter Description
Index
[CostGroupTimebands_T
imebandIndex]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Start Time
[CostGroupTimebands_S
tartTime]
Defines the day and time of day from when this time band is applicable.
The format is DDD:hh:mm, where:
 DDD is the day of the week, represented by the first three letters of the
day in upper case (i.e., SUN, MON, TUE, WED, THU, FRI, or SAT).
 hh and mm denote the time of day, where hh is the hour (00-23) and
mm the minutes (00-59)
For example, SAT:22:00 denotes Saturday at 10 pm.
End Time
[CostGroupTimebands_E
ndTime]
Defines the day and time of day until when this time band is applicable.
For a description of the valid values, see the parameter above.
Connection Cost
[CostGroupTimebands_
ConnectionCost]
Defines the call connection cost during this time band. This is added as a
fixed charge to the call.
The valid value range is 0-65533. The default is 0.
Note: The entered value must be a whole number (i.e., not a decimal).
