Version 7.0 283 Mediant 3000
User's Manual 16. Services
 To configure an HTTP-based service
1. Open the HTTP Remote Services table (Configuration tab > VoIP menu > Services
> HTTP Services > HTTP Remote Services).
2. In the table, select the required HTTP Remote Service index row, and then click the
HTTP Remote Hosts button, located below the table; the HTTP Remote Hosts page
appears.
3. Click Add; the following dialog box appears:
Figure 16-28: HTTP Remote Hosts Table - Add Row Dialog Box
4. Configure an HTTP remote host according to the parameters described in the table
below.
5. Click Add, and then save ("burn") your settings to flash memory.
Table 16-14: HTTP Remote Hosts Table Parameter Descriptions
Parameter Description
Index
[HTTPRemoteHosts_Remo
teHostindex]
Defines an index number for the new table row.
Notes:
 Each row must be configured with a unique index.
 The parameter is mandatory.
Name
[HTTPRemoteHosts_Name
]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 40 characters. By default, no value is
defined.
Notes:
 Each row must be configured with a unique name.
 The parameter is mandatory.
Address
[HTTPRemoteHosts_Addre
ss]
Defines the address (IP address or FQDN) of the host.
The valid value is a string of up to 80 characters.
Notes:
 An IPv6 address can only be configured if the interface is a
CONTROL type.
 If the address is an FQDN and the DNS resolution results in multiple
IP addresses, the device device attempts to establish multiple
connections (sessions) for each IP address. Only the first 10
resolved IP addresses are used regardless of the number of hosts.
To Next Page
