Version 7.0 323 Mediant 3000
User's Manual 18. Control Network
 To configure a Remote Media Subnet:
1. Open the Media Realm table (see ''Configuring Media Realms'' on page 319).
2. Select the Media Realm row for which you want to add Remote Media Subnets, and
then click the Remote Media Subnet link located below the table; the Remote Media
Subnet table appears.
3. Click Add; the following dialog box appears:
Figure 18-3: Remote Media Subnet Table - Add Row Dialog Box
4. Configure the Remote Media Subnet according to the parameters described in the
table below.
5. Click Add.
Table 18-2: Remote Media Subnet Table Parameter Descriptions
Parameter Description
Index
[RemoteMediaSubnet_
RemoteMediaSubnetIn
dex]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
[RemoteMediaSubnet_
RemoteMediaSubnetN
ame]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 20 characters.
Note: Each row must be configured with a unique name.
Prefix Length
[RemoteMediaSubnet_
PrefixLength]
Defines the subnet mask in Classless Inter-Domain Routing (CIDR)
notation. For example, 16 denotes 255.255.0.0.
The default is 16.
Address Family
[RemoteMediaSubnet_
AddressFamily]
Defines the IP address protocol.
 [2] IPv4 (default)
 [10] IPv6
