AudioCodes Mediant 3000 User Manual

Version 7.0 325 Mediant 3000
User's Manual 18. Control Network
2. Select the Media Realm row for which you want to add Remote Media Extensions,
and then click the Media Realm Extension link located below the table; the Media
Realm Extension table appears.
3. Click Add; the following dialog box appears:
Figure 18-5: Media Realm Extension Table - Add Row Dialog Box
4. Configure the Media Realm Extension according to the parameters described in the
table below.
5. Click Add.
Table 18-3: Media Realm Extension Table Parameter Descriptions
Parameter Description
Index
[MediaRealmExtension
_ExtensionIndex]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
IPv4 Interface Name
[MediaRealmExtension
_IPv4IF]
Assigns an IPv4 network interface (configured in the Interface table) to the
Media Realm Extension.
By default, no value is defined (None).
For configuring IP network interfaces, see ''Configuring IP Network
Interfaces'' on page 145.
Note: The parameter is mandatory.
IPv6 Interface Name
[MediaRealmExtension
_IPv6IF]
Assigns an IPv6 network interface (configured in the Interface table) to the
Media Realm Extension.
By default, no value is defined (None).
Note: The parameter is mandatory.
Port Range Start
[MediaRealmExtension
_PortRangeStart]
Defines the first (lower) port in the range of media UDP ports for the Media
Realm Extension.
By default, no value is defined.
Notes:
 You must either configure all your Media Realms with port ranges or all
without; not some with and some without.
 The available UDP port range is according to the BaseUDPport
parameter. For more information, see ''Configuring RTP Base UDP Port''
on page 215.
 The port range must not overlap with any other media port range that
you have configured in the table or in the Media Realm table.
