Version 7.0 329 Mediant 3000
User's Manual 18. Control Network
2. Click Add; the following dialog box appears:
Figure 18-7: SRD Table - Add Row Dialog Box
3. Configure an SRD according to the parameters described in the table below.
4. Click Add.
Table 18-4: SRD Table Parameter Descriptions
Parameter Description
Index
[SRD_Index]
Defines an index for the new table row.
Note: Each row must be configured with a unique index.
Name
[SRD_Name]
Defines an arbitrary name to easily identify the row.
The valid value can be a string of up to 40 characters.
Notes:
 The parameter is mandatory.
 Each row must be configured with a unique name.
Sharing Policy
[SRD_SharingPolicy]
Defines the sharing policy of the SRD, which determines whether the
SRD shares its SIP resources (SIP Interfaces, Proxy Sets, and IP
Groups) with all other SRDs (Shared and Isolated).
 [0] Shared = (Default) SRD shares its resources with other SRDs
(Isolated and Shared) and calls can thus be routed between the SRD
and other SRDs.
 [1] Isolated = SRD does not share its resources with other SRDs and
calls cannot be routed between the SRD and other Isolated SRDs.
However, calls can be routed between the SRD and other Shared
SRDs.
For more information on SRD Sharing Policy, see Multiple SRDs for Multi-
tenant Deployments on page 332.
