AudioCodes Mediant 3000

Version 7.0 349 Mediant 3000
User's Manual 18. Control Network
Parameter Description
Created By Routing
Server
[IPGroup_CreatedByRouti
ngServer]
(Read-only) Indicates whether the IP Group was created by a third-party
routing server:
 [0] No
 [1] Yes
For more information on the third-party routing server feature, see
Centralized Third-Party Routing Server on page 284.
GW Tab (Gateway Application)
SIP Re-Routing Mode
[IPGroup_SIPReRoutingM
ode]
Defines the routing mode after a call redirection (i.e., a 3xx SIP response
is received) or transfer (i.e., a SIP REFER request is received).
 [-1] Not Configured (Default)
 [0] Standard = INVITE messages that are generated as a result of
Transfer or Redirect are sent directly to the URI, according to the
Refer-To header in the REFER message or Con
tact header in the 3xx
response.
 [1] Proxy = Sends a new INVITE to the Proxy. This is applicable only
if a Proxy server is used and the parameter AlwaysSendtoProxy is set
to 0.
 [2] Routing Table = Uses the Routing table to locate the destination
and then sends a new INVITE to this destination.
Notes:
 When the parameter is set to [1] and the INVITE sent to the Proxy
fails, the device re-routes the call according to the Standard mode [0].
 When the parameter is set to [2] and the INVITE fails, the device re-
routes the call according to the Standard mode [0]. If DNS resolution
fails, the device attempts to route the call to the Proxy. If routing to
the Proxy also fails, the Redirect / Transfer request is rejected.
 When the parameter is set to [2], the XferPrefix parameter can be
used to define different routing rules for redirected calls.
 The parameter is ignored if the parameter AlwaysSendToProxy is set
to 1.
Always Use Route Table
[IPGroup_AlwaysUseRout
eTable]
Defines the Request-URI host name in outgoing INVITE messages.
 [0] No (default).
 [1] Yes = The device uses the IP address (or domain name) defined
in the Tel-to-IP Routing table (see Configuring the Tel to IP Routing
on page 496) as the Request-URI host name in outgoing INVITE
messages, instead of the value configured in the 'SIP Group Name'
field.
Note: The parameter is applicable only to Server-type IP Groups.
SBC Tab (SBC Application)
