User's Manual 370 Document #: LTRT-89730
Mediant 3000
3. According to the sub-header present in the WWW-Authenticate header, the correct
REGISTER request is created.
4. Since the algorithm is MD5:
• The username is equal to the endpoint phone number "122".
• The realm return by the proxy is "audiocodes.com".
• The password from the ini file is "AudioCodes".
• The equation to be evaluated is "122:audiocodes.com:AudioCodes". According to
the RFC, this part is called A1.
• The MD5 algorithm is run on this equation and stored for future usage.
• The result is "a8f17d4b41ab8dab6c95d3c14e34a9e1".
5. The par called A2 needs to be evaluated:
• The method type is "REGISTER".
• Using SIP protocol "sip".
• Proxy IP from ini file is "10.2.2.222".
• The equation to be evaluated is "REGISTER:sip:10.2.2.222".
• The MD5 algorithm is run on this equation and stored for future usage.
• The result is "a9a031cfddcb10d91c8e7b4926086f7e".
6. Final stage:
• A1 result: The nonce from the proxy response is
"11432d6bce58ddf02e3b5e1c77c010d2".
• A2 result: The equation to be evaluated is
"A1:11432d6bce58ddf02e3b5e1c77c010d2:A2".
• The MD5 algorithm is run on this equation. The outcome of the calculation is the
response needed by the device to register with the Proxy.
• The response is "b9c45d0234a5abf5ddf5c704029b38cf".
At this time, a new REGISTER request is issued with the following response:
REGISTER sip:10.2.2.222 SIP/2.0
Via: SIP/2.0/UDP 10.1.1.200
From: <sip: 122@10.1.1.200>;tag=1c23940
To: <sip: 122@10.1.1.200>
Call-ID: 654982194@10.1.1.200
Server: Audiocodes-Sip-Gateway/Mediant 3000/v.6.80A.227.005
CSeq: 1 REGISTER
Contact: sip:122@10.1.1.200:
Expires:3600
Authorization: Digest, username: 122,
realm="audiocodes.com”,
nonce="11432d6bce58ddf02e3b5e1c77c010d2",
uri=”10.2.2.222”,
response=“b9c45d0234a5abf5ddf5c704029b38cf”
7. Upon receiving this request and if accepted by the Proxy, the Proxy returns a 200 OK
response, completing the registration transaction:
SIP/2.0 200 OK
Via: SIP/2.0/UDP 10.1.1.200
From: <sip: 122@10.1.1.200>;tag=1c23940
To: <sip: 122@10.1.1.200>
Call-ID: 654982194@10.1.1.200
Cseq: 1 REGISTER
Date: Thu, 26 Jul 2012 09:34:42 GMT
Server: Columbia-SIP-Server/1.17
Content-Length: 0
