User's Manual 418 Document #: LTRT-89730
Mediant 3000
Parameter Description
forwards the received payload type as is).
Fax Coders
[IpProfile_SBCFaxCodersGroup
ID]
Assigns a Coders Group to define the supported fax coders for fax
negotiation for the SIP entity associated with the IP Profile. For
configuring Coder Groups, see Configuring Coder Groups on page
385.
Note: The parameter is applicable only if you set the
IpProfile_SBCFaxBehavior parameter to a value other than [0].
Fax Mode
[IpProfile_SBCFaxBehavior]
Enables the device to handle fax offer-answer negotiations for the
SIP entity associated with the IP Profile.
[0] As Is = (Default) Device forwards fax transparently, without
interference.
[1] Handle always = Handle fax according to fax settings in the
IP Profile for all offer-answer transactions (including the initial
INVITE).
[2] Handle on re-INVITE = Handle fax according to fax settings
in the IP Profile for all re-INVITE offer-answer transactions
(except for initial INVITE).
Note: The fax settings in the IP Profile include
IpProfile_SBCFaxCodersGroupID, IpProfile_SBCFaxOfferMode,
and IpProfile_SBCFaxAnswerMode.
Fax Offer Mode
[IpProfile_SBCFaxOfferMode]
Defines the coders included in the outgoing SDP offer (sent to the
called "fax") for the SIP entity associated with the IP Profile.
[0] All coders = (Default) Use only (and all) the coders of the
selected Coders Group ID configured using the
SBCFaxCodersGroupID parameter.
[1] Single coder = Use only one coder. If a coder in the incoming
offer (from the calling "fax") matches a coder in the
SBCFaxCodersGroupID, the device uses this coder. If no match
exists, the device uses the first coder listed in the Coders Group
ID (SBCFaxCodersGroupID).
Note: The parameter is applicable only if you set the
IpProfile_SBCFaxBehavior parameter to a value other than [0].
Fax Answer Mode
[IpProfile_SBCFaxAnswerMode
]
Defines the coders included in the outgoing SDP answer (sent to
the calling "fax") for the SIP entity associated with the IP Profile.
[0] All coders = Use matched coders between the incoming offer
coders (from the calling "fax") and the coders of the selected
Coders Group ID (configured using the SBCFaxCodersGroupID
parameter).
[1] Single coder = (Default) Use only one coder. If the incoming
answer (from the called "fax") includes a coder that matches a
coder match between the incoming offer coders (from the callin
"fax") and the coders of the selected Coders Group ID
(SBCFaxCodersGroupID, then the device uses this coder. If no
match exists, the device uses the first listed coder of the
matched coders between the incoming offer coders (from the
calling "fax") and the coders of the selected Coders Group ID.
Note: The parameter is applicable only if you set the
IpProfile_SBCFaxBehavior parameter to a value other than [0].
Remote Renegotiate on Fax
Detection
Enables local handling of fax detection and negotiation by the
device on behalf of the SIP entity associated with the IP Profile.
This applies to faxes sent immediately upon the establishment of a
