AudioCodes Mediant 3000 User Manual

Version 7.0 471 Mediant 3000
User's Manual 24. Manipulation
2. Click Add; the following dialog box appears:
Figure 24-2: Number Manipulation Table (Example) - Add Row Dialog Box
3. Configure a number manipulation rule according to the parameters described in the
table below.
4. Click Add.
The table below shows configuration examples of Tel-to-IP source phone number
manipulation rules, where:

Rule 1: When the destination number has the prefix 03 (e.g., 035000), source number
prefix 201 (e.g., 20155), and from source IP Group ID 2, the source number is
changed to, for example, 97120155.

Rule 2: When the source number has prefix 1001 (e.g., 1001876), it is changed to
587623.

Rule 3: When the source number has prefix 123451001 (e.g., 1234510012001), it is
changed to 20018.

Rule 4: When the source number has prefix from 30 to 40 and a digit (e.g., 3122), it is
changed to 2312.

Rule 5: When the destination number has the prefix 6, 7, or 8 (e.g., 85262146),
source number prefix 2001, it is changed to 3146.
Parameter Rule 1 Rule 2 Rule 3 Rule 4 Rule 5
Destination
Prefix
03
* * [6,7,8]
Source Prefix
201 1001 123451001# [30-40]x 2001
Stripped Digits
from Left
- 4 - - 5
Stripped Digits
from Right
- - - 1 -
Prefix to Add
971 5 - 2 3
Suffix to Add
- 23 8 - -
