User's Manual 538 Document #: LTRT-89730
Mediant 3000
 To configure AOC:
1. Make sure that the PSTN protocol for the trunk line is Euro ISDN and set to network
side.
2. Make sure that the date and time of the device is correct. For accuracy, it is
recommended to use an NTP server to obtain the date and time.
3. Configure the required AOC method:
• Device Generation of AOC to Tel:
a. On the Supplementary Services page (Configuration tab > VoIP menu >
GW > DTMF and Supplementary > Supplementary Services), set the
'Generate Metering Tones' parameter (PayPhoneMeteringMode) to Internal
Table.
b. Configure the Charge Codes in the Charge Codes table (''Configuring
Charge Codes'' on page 539).
c. Assign the Charge Code index to the relevant Tel-to-IP routing rule in the
Tel-to-IP Routing table (see ''Configuring Tel-to-IP Routing Rules'' on page
496).
• AOC in the Tel-to-IP Direction: On the Supplementary Services page
(Configuration tab > VoIP menu > GW > DTMF and Supplementary >
Supplementary Services), set 'AoC Support' to Enable, to enable the AOC
service for sending AOC to IP.
• AOC in the IP-to-Tel Direction: On the Supplementary Services page
(Configuration tab > VoIP menu > GW > DTMF and Supplementary >
Supplementary Services), configure the 'Generate Metering Tones' parameter
(PayPhoneMeteringMode) to the required method (SIP Interval Provided, SIP
RAW Data Provided, SIP RAW Data Incremental Provided, or SIP 2 TEL
INTERWORKING).
Note: This feature is applicable to Euro ISDN ().
