User's Manual 598 Document #: LTRT-89730
Mediant 3000
2. Click Add; the following dialog box appears:
Figure 33-2: Classification Table - Add Row Dialog Box
3. Configure the Classification rule according to the parameters described in the table
below.
4. Click Add.
Table 33-1: Classification Table Parameter Descriptions
Parameter Description
Index
[Classification_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
[Classification_Classificat
ionName]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 20 characters. By default, no name is
defined.
Note: Each row must be configured with a unique name.
Rule (Matching Characteristics)
SRD
[Classification_SRDNam
e]
Assigns an SRD to the rule as a matching characteristic for the incoming
SIP dialog.
If only one SRD is configured in the SRD table, the SRD is assigned to
the rule, by default. If multiple SRDs are configured in the SRD table, no
value is assigned.
For configuring SRDs, see ''Configuring SRDs'' on page 326.
Note: The parameter is mandatory.
Source SIP Interface
[Classification_SrcSIPInt
Assigns a SIP Interface to the rule as a matching characteristic for the
incoming SIP dialog.
The default is Any (i.e., all SIP Interfaces belonging to the SRD assigned
To Next Page
