Version 7.0 607 Mediant 3000
User's Manual 33. Routing SBC
destination for the calls. For more information on prefix tags, see ''Dial Plan Prefix
Tags for SBC IP-to-IP Routing'' on page 688.
Note: Call forking is not applicable to LDAP-based IP-to-IP routing rules.
The following procedure describes how to configure IP-to-IP routing rules through the Web
interface. You can also configure it through ini file (IP2IPRouting).
 To configure an IP-to-IP routing rule:
1. Open the IP-to-IP Routing table (Configuration tab > VoIP menu > SBC > Routing
SBC > IP-to-IP Routing Table).
2. Click Add; the following dialog box appears:
Figure 33-5: IP-to-IP Routing Table - Add Row Dialog Box
3. Configure an IP-to-IP routing rule according to the parameters described in the table
below.
4. Click Add.
Table 33-3: IP-to-IP Routing Table Parameter Descriptions
Parameter Description
Index
[IP2IPRouting_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Routing Policy
Assigns an SBC Routing Policy to the rule. The SBC Routing Policy
associates the rule with an SRD(s). The SBC Routing Policy also defines
default LCR settings as well as the LDAP servers used if the routing rule
