AudioCodes Mediant 3000 User Manual

User's Manual 618 Document #: LTRT-89730
Mediant 3000
Notes:
• The Classification table is used only if classification by registered user in the
device's users registration database or by Proxy Set fails.
• If the device receives incoming calls (e.g., INVITE) from users that have already
been classified and registered in the device's registration database, the device
ignores the Classification table and uses the Routing Policy that was determined
for the user during the initial classification process.
The following procedure describes how to configure SBC Routing Policy rules through the
Web interface. You can also configure it through ini file (SBCRoutingPolicy).
 To configure an SBC Routing Policy rule:
1. Open the SBC Routing Policy table (Configuration tab > VoIP menu > SBC >
Routing SBC > SBC Routing Policy).
2. Click Add; the following dialog box appears:
Figure 33-7: SBC Routing Policy Table - Add Row Dialog Box
3. Configure the SBC Routing Policy rule according to the parameters described in the
table below.
4. Click Add.
Table 33-5: SBC Routing Policy Table Parameter Descriptions
Parameter Description
Index Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
[SBCRoutingPolicy_Nam
e]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 41 characters. By default, no name is
defined. If you don't configure a name, the device automatically assigns a
name in the following format: "SBCRoutingPolicy_<Index>", for example,
"SBCRoutingPolicy_2".
Note: Each row must be configured with a unique name.
LDAP Servers Group
Name
[SBCRoutingPolicy_
LdapServersGroupNa
me]
Assigns an LDAP Server Group to the Routing Policy. Routing rules in the
IP-to-IP Routing table that are associated with the Routing Policy and that
are configured with LDAP and/or Call Setup Rules, use the LDAP
server(s) configured for this LDAP Server Group.
By default, no value is defined (None).
For more information on LDAP Server Groups, see ''Configuring LDAP
