Version 7.0 631 Mediant 3000
User's Manual 34. SBC Manipulations
Parameter Description
Call Trigger
[IPOutboundManipulation
_Trigger]
Defines the reason (i.e., trigger) for the re-routing of the SIP request:
 [0] Any = (Default) Re-routed for all scenarios (re-routes and non-re-
routes).
 [1] 3xx = Re-routed if it triggered as a result of a SIP 3xx response.
 [2] REFER = Re-routed if it triggered as a result of a REFER request.
 [3] 3xx or REFER = Applies to options [1] and [2].
 [4] Initial only = Regular requests that the device forwards to a
destination. In other words, re-routing of requests triggered by the
receipt of REFER or 3xx does not apply.
Action
Manipulated Item
[IPOutboundManipulation
_IsAdditionalManipulatio
n]
Defines the element in the SIP message that you want manipulated.
 [0] Source URI = (Default) Manipulates the source SIP Request-URI
user part.
 [1] Destination URI = Manipulates the destination SIP Request-URI
user part.

[2]
Calling Name = Manipulates the calling name in the SIP message.
Remove From Left
[IPOutboundManipulation
_RemoveFromLeft]
Defines the number of digits to remove from the left of the manipulated
item prefix. For example, if you enter 3 and the user name is "john", the
new user name is "n".
Remove From Right
[IPOutboundManipulation
_RemoveFromRight]
Defines the number of digits to remove from the right of the manipulated
item prefix. For example, if you enter 3 and the user name is "john", the
new user name is "j".
Leave From Right
[IPOutboundManipulation
_LeaveFromRight]
Defines the number of digits to keep from the right of the manipulated
item.
Prefix to Add
[IPOutboundManipulation
_Prefix2Add]
Defines the number or string to add in the front of the manipulated item.
For example, if you enter 'user' and the user name is "john", the new user
name is "userjohn".
If you set the 'Manipulated Item' parameter to Source URI or Destination
URI, you can configure the parameter to a string of up 49 characters. If
you set the 'Manipulated Item' parameter to Calling Name, you can
configure the parameter to a string of up 36 characters.
Suffix to Add
[IPOutboundManipulation
_Suffix2Add]
Defines the number or string to add at the end of the manipulated item.
For example, if you enter '01' and the user name is "john", the new user
name is "john01".
If you set the 'Manipulated Item' parameter to Source URI or Destination
URI, you can configure the parameter to a string of up 49 characters. If
you set the 'Manipulated Item' parameter to Calling Name, you can
configure the parameter to a string of up 36 characters.
Privacy Restriction Mode
[IPOutboundManipulation
_PrivacyRestrictionMode]
Determines user privacy handling (i.e., restricting source user identity in
outgoing SIP dialogs).
 [0] Transparent = (Default) No intervention in SIP privacy.
 [1] Don't change privacy = The user identity remains the same as in
