User's Manual 660 Document #: LTRT-89730
Mediant 3000
IP Address Description
IP Address Application VLAN ID
192.168.85.14 Management (OAMP) address 1
200.200.85.14 Call Control address 200
211.211.85.14
RTP Media address and with default gateway
211.211.85.1
211
Private IP Addresses of the Blades
192.168.85.15 Blade in Slot 1 (received from BootP)
192.168.85.16 Blade in Slot 3 (received from BootP)
Table 38-3: Example of Multiple Interfaces for Mediant 3000 HA in Interface Table
Index
Applicatio
n Type
Interfac
e Mode
IP Address
Prefix
Lengt
h
Gateway
VLA
N ID
Interface
Name
Primary /
Secondary
DNS Server
IP Address
0 OAMP
IPv6
Manual
192.168.85.
14
16
192.168.0.
1
1
Management
IF
-
1 Control
IPv6
Manual
200.200.85.
14
24
200.200.8
5.1
200 myControlIF -
2 Media
IPv6
Manual
211.211.85.
14
24
211.211.8
5.1
211 myMediaIF -
2. VLANs are required and the Native VLAN ID is the same VLAN ID as the
Management interface (configured for Index 0):
• 'VLAN Mode' is set to Enable.
• 'Native VLAN ID' field is set to "1".
3. IP Routing table: One routing rule is required to allow remote management from a
host in 176.85.49.0 / 24:
Table 38-4: Example of IP Routing Table
Destination IP
Address
Prefix Length
Gateway IP
Address
Metric Interface Name
176.85.49.0 24 192.168.0.10 1 0
4. All other parameters are set to their respective default values.
Notes:
• Ensure that the private addresses of the blades are not configured in the Interface
table.
• The same configuration must be done for both blades.
