User's Manual 734 Document #: LTRT-89730
Mediant 3000
When Physical Network Separation is enabled on Mediant 3000 with TP-8410 (see
Physical Network Separation Mode on page 661), the Ethernet Port Information page
displays the different ports allocated for the OAMP, Media and Control network interfaces.
The following figure shows an example when dedicated ports are used for each traffic type:
Figure 48-1: Ethernet Port Page for Physical Network Separation (Mediant 3000 with TP-8410)
Table 48-1: Ethernet Port Information Parameters
Parameter Description
Port Name Displays the name of the port.
Active Port Displays the active Ethernet port (1 or 2).
Port Duplex Mode Displays whether the port is in half or duplex mode.
Port Speed Displays the speed (in Mbps) of the Ethernet port.
