User's Manual 750 Document #: LTRT-89730
Mediant 3000
To view IP-to-Tel and Tel-to-IP call counters:
Open the Call Counters page that you want to view (Status & Diagnostics tab > VoIP
Status menu > IP to Tel Calls Count or Tel to IP Calls Count); the figure below
shows the IP to Tel Calls Count page.
Figure 51-6: Calls Count Page
The fields in this page are described in the following table:
Table 51-3: Call Counters Description
Counter Description
Number of Attempted
Calls
Indicates the number of attempted calls. It is composed of established
and failed calls. The number of established calls is represented by the
'Number of Established Calls' counter. The number of failed calls is
represented by the failed-call counters. Only one of the established /
failed call counters is incremented every time.
Number of Established
Calls
Indicates the number of established calls. It is incremented as a result of
one of the following release reasons if the duration of the call is greater
than zero:
GWAPP_REASON_NOT_RELEVANT (0)
GWAPP_NORMAL_CALL_CLEAR (16)
GWAPP_NORMAL_UNSPECIFIED (31)
And the internal reasons:
RELEASE_BECAUSE_UNKNOWN_REASON
RELEASE_BECAUSE_REMOTE_CANCEL_CALL
RELEASE_BECAUSE_MANUAL_DISC
RELEASE_BECAUSE_SILENCE_DISC
RELEASE_BECAUSE_DISCONNECT_CODE
Note: When the duration of the call is zero, the release reason
GWAPP_NORMAL_CALL_CLEAR increments the 'Number of Failed
Calls due to No Answer' counter. The rest of the release reasons
increment the 'Number of Failed Calls due to Other Failures' counter.
Percentage of
Successful Calls (ASR)
The percentage of established calls from attempted calls.
Number of Calls
Terminated due to a
Busy Line
Indicates the number of calls that failed as a result of a busy line. It is
incremented as a result of the following release reason:
GWAPP_USER_BUSY (17)
Number of Calls
Terminated due to No
Indicates the number of calls that weren't answered. It's incremented as
a result of one of the following release reasons:
