AudioCodes Mediant 3000 User Manual

Version 7.0 777 Mediant 3000
User's Manual 52. Reporting Information to External Party
An example of CDR customization rules configured in the table is shown below:
Figure 52-5: Example of CDR Customization Rules for SBC Calls
SBC CDR Format Table Parameter Descriptions
Parameter Description
Index
[SBCCDRFormat_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
CDR Type
cdr-type
[SBCCDRFormat_CDRT
ype]
Defines the application type for which you want to customize CDRs.
 [1] Syslog SBC = (Default) Customizes CDR fields for SIP signaling-
related CDRs sent in Syslog messages.
 [3] Syslog Media = Customizes CDR fields for media-related CDRs
sent in Syslog messages.
 [7] RADIUS SBC = Customizes CDR fields (i.e., RADIUS Attributes)
for CDRs sent in RADIUS accounting request messages.
Column Type
col-type
[SBCCDRFormat_Colum
nType]
Defines the CDR field (column) that you want to customize. The
applicable CDR field depends on the settings of the 'CDR Type'
parameter:
 For all types: [0] CDR Type (default); [1] Call ID; [2] Session ID; [3]
Report Type; [4] Media Type; [5] Accounting Status Type; [6] H323
ID; [7] Radius Call ID; [8] Blank.
 Syslog SBC and RADIUS SBC: [10] Endpoint Type; [11] Call Orig;
[12] Source IP; [13] Destination IP; [14] Remote IP; [15] Source Port;
[16] Dest Port; [17] Remote Port; [18] Call Duration; [19] Termination
Side; [20] Termination Reason; [21] Setup Time; [22] Connect Time;
[23] Release Time; [24] Redirect Reason; [25] Was Call Started; [26]
IP Group ID; [27] IP Group Name; [28] SRD ID; [29] SRD Name; [30]
SIP Interface ID; [31] Transport Type; [32] Signaling IP DiffServ; [33]
Termination Reason Category; [34] Proxy Set ID; [35] IP Profile ID;
[36] IP Profile Name; [37] Media Realm ID; [38] Media Realm Name;
[39] SIP Termination Reason; [40] SIP Termination Description; [41]
Caller Display ID; [42] Callee Display ID; [43] SIPInterface Name; [44]
Call Orig Radius; [45] Termination Side Radius; [46] Termination Side
Yes No; [47] Termination Reason Value; [48] ProxySet Name.
 Syslog Media and RADIUS SBC: [150] Channel ID; [151] Coder
Type;[152] Packet Interval; [153] Payload Type; [154] Local Input
Packets; [155] Local Output Packets; [156] Local Input Octets; [157]
Local Output Octets; [158] Local Packet Loss; [159] Local Round Trip
Delay; [160] Local Jitter; [161] Local SSRC Sender; [162] Remote
Input Packets; [163] Remote Output Packets; [164] Remote Input
Octets; [165] Remote Output Octets; [166] Remote Packet Loss; [167]
Remote Round Trip Delay; [168] Remote Jitter; [169] Remote SSRC
Sender; [170] Local RTP IP; [171] Local RTP Port; [172] Remote RTP
IP; [173] Remote RTP Port; [174] RTP IP DiffServ; [175] Local R
Factor; [176] Remote R Factor; [177] Local MOS CQ; [178] Remote
MOS CQ; [179] AMD Decision; [180] AMD Decision Probability; [181]
Latched RTP IP; [182]Latched RTP Port; [183] Latched T38 IP; [184]
Latched T38 Port.

Syslog SBC and RADIUS SBC: [200] Source URI; [201] Destination
