AudioCodes Mediant 3000 User Manual

User's Manual 908 Document #: LTRT-89730
Mediant 3000
Parameter Description
[EnableReasonHeader]

[0] Disable
 [1] Enable (default)
Gateway Name
[SIPGatewayName]
Defines a name for the device (e.g., device123.com). This name is used
as the host part of the SIP URI in the From header. If not specified, the
device's IP address is used instead (default).
Notes:
 Ensure that the parameter value is the one with which the Proxy has
been configured with to identify the device.
 The parameter can also be configured for an IP Group (in the IP
Group table).
[ZeroSDPHandling] Determines the device's response to an incoming SDP that includes an
IP address of 0.0.0.0 in the SDP's Connection Information field (i.e.,
"c=IN IP4 0.0.0.0").
 [0] = (Default) Sets the IP address of the outgoing SDP's c= field to
0.0.0.0.
 [1] = Sets the IP address of the outgoing SDP c= field to the IP
address of the device. If the incoming SDP doesn’t contain the
"a=inactive" line, the returned SDP contains the "a=recvonly" line.
Enable Delayed Offer
[EnableDelayedOffer]
Determines whether the device sends the initial INVITE message with or
without an SDP. Sending the first INVITE without SDP is typically done
by clients for obtaining the far-end's full list of capabilities before sending
their own offer. (An alternative method for obtaining the list of supported
capabilities is by using SIP OPTIONS, which is not supported by every
SIP agent.)
 [0] Disable = (Default) The device sends the initial INVITE message
with an SDP.
 [1] Enable = The device sends the initial INVITE message without an
SDP.
[DisableCryptoLifeTimeIn
SDP]
Enables the device to send "a=crypto" lines without the lifetime
parameter in the SDP. For example, if the SDP contains "a=crypto:12
AES_CM_128_HMAC_SHA1_80
inline:hhQe10yZRcRcpIFPkH5xYY9R1de37ogh9G1MpvNp|2^31", it
removes the lifetime parameter "2^31".
 [0] Disable (default)
 [1] Enable
Enable Contact Restriction
[EnableContactRestriction]
Determines whether the device sets the Contact header of outgoing
INVITE requests to ‘anonymous’ for restricted calls.
 [0] Disable (default)

[1]
Enable
[AnonymousMode]
Determines whether the device's IP address is used as the URI host part
instead of "anonymous.invalid" in the INVITE's From header for Tel-to-IP
calls.
 [0] = (Default) If the device receives a call from the Tel with blocked
caller ID, it sends an INVITE with
From: “anonymous”<anonymous@anonymous.invalid>
 [1] = The device's IP address is used as the URI host part instead of
"anonymous.invalid".
The parameter may be useful, for example, for service providers who
identify their SIP Trunking customers by their source phone number or IP
address, reflected in the From header of the SIP INVITE. Therefore,
